SUCCESS CASES ACCIO Engineering proposes services in electrical engineering, instrumentation and process automatic control.

We offer services ranging from technical support and maintenance to turn key projects.

We perform upgrades and migrations in different control technologies.
automatización
Optimization and Industrial Automatization
Industria de alimentos
  • Mechanical design, manufacturing and automation of metering flavoring machine (color, flavor, aroma) for gelatin Lala, dosed with capacity 1-5 ​​ml per container + -2% accuracy. 24 points of injection, dose rate 3456 per minute maximum, the system includes 7 servo-motors network with a PLC Siemens S7 300 and an SEW Eurodrive MOVIPLC and synchrony with the main station through a Telemecanique PLC.
    dosi

    dosi2
  • Automation pasteurization process energy drinks (flow of 20 m3 / h). The process includes online cleaning system, viewing and programming PLC WinCC S7-315-2DP used Ethernet, Profibus DP, PA and AS-i. Project carried out in Venezuela.
  • Automation-online-standardization of protein and fat content of milk (flows 25-50 m3 / h) by modulating valves in the reception area. Display WinCC and S7 414 PLC programming using Ethernet, Profibus and AS-i.
  • Automatic control of continuous milk standardization (fat and protein content control). The standardized milk flow rate varied from 50 to 25 to m3/h, depending on the type of raw milk. The process was controlled by a valve control system. Visualization was developed in WinCC and the control was delivered by PLC S7 414 using Ethernet, Profibus and ASi networks.
  • Programming to incorporate 70 new valves into a controlled cheese maturation, fermentation, and yogurt process. The new system was controlled by a PLC S7 416 using Ethernet, Profibus and ASi networks. The visualization was developed in WinCC.
  • Conception of an on-line maintenance database: Database multiuser (20 individuals)that allows the capture, analysis, and drawing of statistic graphs of the Danone’s process equipment breakdowns and the solutions applied. The process includes: 420 equipments controlled by 120 PLCs.
  • Automatic control (Control Panel assembly, PLC programming, motors and sensors connection) of a packaging machine (1800 packages per hour) using Siemens PLC S7 300.
  • Automatic control (Control Panel assembly, PLC programming, motors and sensors connection) of bottom-up bottle-filling machine (19,000 bottles per hour) using Siemens PLC S7 300. Complete automatic control (operating panel, PLC, motors and sensors).
  • Automatic control of a milk, juice, and yogurt pasteurizer. Programming performed in Allen Bradley 1200 and visualization on Touch Screen PV 300
  • Automatic control of cheese molder 2800 pieces/h. Programming performed in Allen Bradley 1200.
  • Installation of 300KVA Emergency Plant
Automotive Industry

>>  Servo-positioning of automatic transmission parts for milling machine with helical gears based Sew Eurodrive and Fanuc technology.

>>  Design and setting-up of a continuous feed system for linking parts of machines within a production line of bearings. The setting-up comprises 2 elevators and 1 horizontal conveyor. Siemens S7-200 PLC.

Read more ...
Steel Industry

>>  Panel assembly, programming, and wiring of a wire strand machine (10 heads). Programming performed in PLC (S7 Siemens) with Touch Screen.

>>  Electric and control assembly of a 4000A electrolytic galvanizing machine. Programming performed in PLC and communications Profibus protocol.

Read more ...
Tanning Industry

>>  Automatic control a leather tanning process (6 baths). Including: receipt management, batch traceability of the mechanical behavior, and production time (1-year of historical data). Turn-key project. Programming performed in Siemens S7, Visual Basic, SQL and ActiveX Controllers, visualization performed in a conventional PC.

>>  Electrical plant installation, three-phases, 440 V, 100A.

Read more ...
Industry of the Construction

>>  Automatic control (design, wiring and connection, programming and commissioning) of a continuous roof tile tray conveyor (including emergency bypass and buffer), rate: 2,100 pieces/h. Programming was developed in PLC (Siemens 300 with, Profibus communication protocol) and linked to an Omron’s PLC (CQM1).

>>  Automatic control system to allow two presses to work in a synchronous way during the roof tile manufacturing process. Turn-key project including design, assembly, programming, test and commissioning. Before this project, each press was operating simultaneously.

Read more ...
Chemical and plastic industry

>>  3-Capacitor arrangement assembly (900 kVAr).

>>  Control panel design and assembly (Siemens S7-200) of a thermoplastic process machine.

>>  Electrical Revamping of a plastics process machine.
Textile Industry

>>  Control system design and assembly to supervise the production of 40 textile labels manufacturing machines. Programming performed in PLC (Siemens S7), visualization and traceability programmed in Visual BASIC.
Other Projects

>>  Electrical wiring diagnosis in 6 schools of the SEP-Guanajuato, the Research Center in Optics, A.C. and of the Agriculture Institute in Celaya, Gto.

>>  Electrical wiring diagnosis in the Campestre Club of Aguascalientes, Ags.

>>   Electrical wiring diagnosis of the Municipal Palace of the H. Ayuntamiento de Leon de los Aldama, Gto.
